This machine fits for drying and sterilizing powders, granular, sheet-like or gel-like food, and additive, spices, flavoring, medicine, raw material of herbal medicine, nutritional health products, agricultural & sideline products, non-fired(or oil saving)instant noodles,
noodles,
rice powder needles, soy products, beef jerky, preserved
meat, dried fish, tea, tobacco and so on; and for drying, peeling and baking almond, peach kernel, groundnut kernels, chestnut and so on; and for puffing of leisure
food, pachyrhizus chips,
potato chips, dried shrimps, fish maw and so on; and for thawing the frozen fish, poultry; and for drying beans; and for drying and desulfurating and deoxidizing the metallurgical chemical products; and for drying printing and dyeing products, ceramics, glass, chemical fiber, cotton yarn, wood, leather, bamboo products, insulation materials, building materials, wood , cork, alveolate, cardboard,corrugated cardboard, and so on.
Features
1. The equipment use advanced production technology, adopt Pannasonic magnetron, long life, best effect.
2. Adopt 304#stainless steel, compact structure, no energy dissipation, save energy.
3. Tunnel type design, cover small area, fast drying and sterilizing, continuous production.
4. Drying and sterilization simultaneously, one equipment has many usages.
5. Low temperature sterilization, keep the original nutrition, color and taste.
Technical parameter
Power supply | 380V±10% 50HZ±1% three-phase five-wire |
Microwave Output Frequency | 2450±50MHz |
Microwave input apparent power | 56KVA |
Microwave output power | 40KW |
Microwave power adjustment range | 0-40KW(adjustable) |
Ambient temperature | -5-40°C |
Dehydrate | 40-48kg/h |
Relative humidity | 80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas |
Overall dimension(L*W*H) | 10680*1440*1750 mm |
Transmission speed | 0-10m/min(adjustable) |
Height of the inlet and outlet | 60 mm |
Microwave leak | accord with a country GB10436-89 standards(<5 mw/cm^2) |
Equipment safety | accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery health security index |
